Ubiquiti Networks ES-10X Edge Switch 10X Gigabit PoE-Compliant Managed with SFP


Specifications

      Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Ubiquiti Networks
  • Model: ES-10X
  • UPC: 817882025188
      Feature:
  • Port Monitoring
  • Virtual Local Area Network (VLAN) Configuration
  • Spanning Tree Protocol (STP, MSTP, and RSTP)
  • Device Discovery Tool
  • Jumbo Frame Support
  • DHCP Snooping
  • Port Isolation
  • Ping Watchdog
      Protocols:
  • Layer Services Supported: Layer 2 Support
  • Transmission Method: Store-and-Forward
      Performance:
  • Forwarding Rate: 14.88 Mpps
      Switching Bandwidth:
  • 20 Gb/s
  • 10 Gb/s (Non-Blocking)
      Electrical:
  • Power Draw: 8.0 W (Max)
  • DC Input Power: 9 to 30 VDC at 1 A
  • PoE Power Budget: 15 W
  • PoE per Port: 15 to 15 W
  • Power Supply Type: Internal
      Environmental:
  • Operating Temperature: 14 to 122°F / -10 to 50°C
  • Operating Humidity: 5 to 95%
      General:
  • Cooling System: Passive
  • Dimensions: 8.15 x 3.54 x 1.22" / 207 x 90 x 31.1 mm
  • Weight: 1.1 lb / 500 g
      Packaging Info:
  • Package Weight: 1.575 lb
  • Box Dimensions (LxWxH): 9.6 x 5 x 3.5"

Features

Brand:
Ubiquiti Networks
Conditions:
New
GTIN, UPC, EAN, JAN or ISBN:
817882025188
Warranty:
1 Year
