Home Networking Wireless Accessories Ubiquiti Networks AirMAX AM-V2G-TI Titanium Sector Advanced RF Isolation Variable Beamwidth Antenna (Grey)

Ubiquiti Networks AirMAX AM-V2G-TI Titanium Sector Advanced RF Isolation Variable Beamwidth Antenna (Grey)


Specifications

      Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Ubiquiti Networks
  • Model: AM-V2G-TI
  • Series: AirMAX

    KEY FEATURES
  • Carrier-Class 2x2 MIMO PtMP BaseStation
  • Works Seamlessly with Rocket M2 Radios
  • 2.3 to 2.6 GHz Frequency Range
  • Adjustable Beamwidth Configuration
  • Reduced Co-Location Interference
  • Equipped with Built-In Rocket Mount
  • Custom-Designed Protective Shroud
  • Pole Mount Kit Included

    SPECIFICATIONS
  • Frequency Range: 2.3 to 2.6 GHz
  • Beam width Angles: 60 Degree
  • 90 Degree
  • 120 Degree
  • Gain (Beam width Dependent): 17 dBi at 60°
  • 16 dBi at 90 Degree
  • 15 dBi at 120 Degree
  • Elevation Beam width: 4 Degree
  • Electrical Downtilt: 4 Degree
  • Wind Survivability: 125 mph (201 km/h)
  • Wind Loading: 92 lb (41.7 kg) at 100 mph (161 km/h)
  • Polarization: Dual Linear
  • Cross-Pol Isolation: 25 dB (typical)
  • Front-to-Back Ratio: 30 dB (typical)
  • Maximum VSWR: 1.5:1
  • RF Connectors: Weatherproof RP-SMA Connectors x 2
  • Compatible Radios: Rocket M2
  • Rocket M2 Titanium
  • Mounting: Pole Mount Kit (included)
  • ETSI Specification: EN 302 326 DN2
  • Certifications: CE, FCC, IC
  • Dimensions (WxHxD): 14.7 x 30.4 x 4.7 Inches (372 x 773 x 120 mm)
  • Weight: 14.1 lb (6.4 kg) with brackets

    Packaging Info
  • Package Weight: 18.7 lb
  • Box Dimensions (LxWxH): 31.5 x 17.1 x 7.5 Inches

Features

Brand:
Ubiquiti Networks
Color:
Grey
Conditions:
New
Warranty:
1 Year
