Home Networking Network Switches TP-Link TPL-TL-SG3428XPP-M2 JetStream 24-Port 2.5GBASE-T And 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ (Black)

TP-Link TPL-TL-SG3428XPP-M2 JetStream 24-Port 2.5GBASE-T And 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ (Black)


Brand:

Specifications

   Product details:
  • 3 Years Warranty
  • Brand: TP-Link
  • Model: TPL-TL-SG3428XPP-M2
  • UPC Code: 4897098689738
   Specification:
  • Fan Quantity: 3 Fan
  • power supply: 100-240VAC~50/60Hz
  • Assembly: Rack mountable
  • Maximum power consumption: 629.1W (110V/60Hz)
  • Maximum heat emission: 2153.45 BTU/hr (110V/60Hz)
   Interface:
  • 24× 2.5 Gbps RJ45 ports
  • 4× 10G SFP+ slots
  • 1× RJ45 console port
  • 1× Micro-USB console port
   PoE ports:
  • Standard: 802.3bt/at/af compliant
  • PoE++ ports(802.3bt PoE): 8 ports, up to 60 W per port
  • PoE+ ports(802.3at PoE): 16 ports, up to 30 W per port
  • Power budget: 500W
   PERFORMANCE:
  • switching capacity: 200 Gbps
  • packet forwarding rate: 148.80 Mpps
  • MAC address table: 32K
  • packet buffer memory: 16 Mbit
  • jumbo frames: 9KB
   Quality of service:
  • 8 priority queues
  • 802.1p CoS/DSCP priority
  • Queue scheduling
  • SP (Strict Priority)
  • WRR (Weighted Round Robin)
  • SP+WRR
  • Bandwidth Control
  • Port/Flow based Rating Limiting
  • Smoother Performance
  • Action for Flows
  • Mirror (to supported interface)
  • Redirect (to supported interface)
  • Rate Limit
  • QoS Remark
   Layer2 and Layer2+ functions:
  • Link Aggregation
  • static link aggregation
  • 802.3ad LACP
  • Up to 8 aggregation groups, containing 8 ports per group
  • Spanning Tree Protocol
  • 802.1d STP
  • 802.1w RSTP
  • 802.1s MSTP
  • STP Security: TC Protect, BPDU Filter, Root Protect
  • Loopback Detection
  • Port based
  • VLAN based
  • Flow Control
  • 802.3x Flow Control
  • HOL Blocking Prevention
  • Mirroring
  • Port Mirroring
  • CPU Mirroring
  • One to One
  • Many to One
  • Tx/Rx/Both



Features

Brand:
TP-Link
Color:
Black
Conditions:
New
GTIN, UPC, EAN, JAN or ISBN:
4897098689738
Warranty:
3 Years
