Home Networking Network Switches TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots

TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
Previous
  1. TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
  2. TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
  3. TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots
Next

TP-Link T2500G-10TS (TL-SG3210) JetStream 8-Port Gigabit L2 Managed Switch with 2 SFP Slots

Brand:
TP-Link

Specifications

   Product details:
  • Brand: TP-LINK
  • 3 Years Warranty
  • Model: T2500G-10TS (TL-SG3210)
   Features:
  • L2 Features: Link Aggregation, static link aggregation, 802.3ad LACP, Up to 8 aggregation groups, containing 8 ports per group
  • Spanning Tree Protocol: 802.1D STP, 802.1w RSTP, 802.1s MSTP, STP Security: Loop Protect, TC Protect, BPDU Filter/Protect, Root Protect
  • Loopback Detection
  • Flow Control: 802.3x Flow Control, HOL Blocking Prevention
  • Port Mirroring: One-to-One, Many-to-One, Flow-Based, Tx/Rx/Both
  • LLDP, LLDP-MED
  • DHCP VLAN Relay
  • L2PT


  • Highlights:
  • Gigabit Ethernet connections on all ports provide full speed of data transferring
  • Selective RJ45 console port and Micro-USB console port
  • Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X and Radius Authentication
  • L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
  • Web/CLI managed modes, SNMP, RMON and Dual Image bring abundant management features

    Hardware Features And Performance:
    General:
  • Standard and Protocols: IEEE 802.3i 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX/FX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-X, IEEE 802.3x Flow control, IEEE 802.3ad Link Aggregation, IEEE 802.1d Spanning Tree Protocol (STP), IEEE 802.1s Rapid Spanning Tree (RSTP), IEEE 802.1w Multiple Spanning Tree (MSTP), IEEE 802.1q VLAN, IEEE 802.1x Port-based Network Access Control, IEEE 802.1p QoS
  • Network Media: 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100 m) 1000BASE-X: MMF, SMF
  • Interface: 8 10/100/1000 Mbps RJ45 ports, 2 Gigabit SFP Slots
  • Console Port: 1 RJ45 Console Port, 1 Micro-USB Console port

    Performance:
  • Switching Capacity: 20 Gbps
  • Packet Forwarding Rate: 14.9 Mpps
  • MAC Address Table: 8K
  • Packet Buffer: 4.1 Mbit
  • Jumbo Frame: 9216 Bytes

    Physical And Environment:
  • Power Supply: 100-240 V AC, 50/60 Hz
  • Max Power Consumption: 6.836 W (220 V/50 Hz)
  • Max Heat Dissipation: 23.32 BTU/h
  • Dimensions (W × D × H): 11.6 × 7.1 × 1.7 in. (294 × 180 × 44 mm)
  • Fan Quantity: Fanless
  • Operating Temperature: 0 °C–45 °C (32 °F–113 °F)
  • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F)
  • Operating Humidity: 10%–90%RH, non-condensing
  • Storage Humidity: 5%–90%RH, non-condensing
  • Certification: CE, FCC

     L2 Multicast:
  • Supports 512 (IPv4,IPv6) multicast groups
  • IGMP Snooping, IGMP v1/v2/v3 Snooping, IGMP Fast Leave, IGMP Snooping Querier, IGMP Authentication, Static Group Config
  • MLD Snooping: MLD v1/v2 Snooping, MLD Snooping Querier, Fast Leave, Limited IP Multicast, IGMP Authentication, Static Group Config
  • MVR
  • Multicast Filtering

    VLAN:
  • VLAN Group: Max. 4K VLAN Groups
  • 802.1Q tag VLAN
  • MAC VLAN
  • Protocol VLAN
  • VLAN VPN (QinQ)
  • GVRP

    QoS:
  • 802.1p CoS/DSCP priority
  • 8 Priority Queues
  • Queue scheduling: SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR
  • Bandwidth Contro: Port/Flow based Rating Limiting
  • Smoother Performance: Mirror (to supported interface), Redirect (to supported interface), Rate Limit, QoS Remark
  • Voice VLAN

    ACL:
  • Supports up to 64 entries: (up to 254 by SDM Template)
  • MAC ACL: Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type
  • IP ACL: Source IP, Destination IP, IP Protocol, TCP Flag, TCP/UDP Port, DSCP/IP TOS
  • Combined ACL: IPv6 ACL
  • Policy: Redirect, Rate Limit, QoS Remark
  • ACL apply to Port/VLAN

    Security:
  • IP-MAC-Port Binding: DHCP Snooping, ARP Inspection, IPv4 Source Guard
  • IPv6-MAC-Port Binding: DHCPv6 Snooping, ND Detection, IPv6 Source Guard
  • DoS Defend
  • Static/Dynamic Port Security, Up to 64 MAC addresses per port
  • Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode
  • 802.1X: Port based authentication, MAC based authentication, Guest VLAN, Support Radius authentication and accountability
  • AAA
  • Port Isolation
  • Secure web management through HTTPS with SSLv3/TLS1.0
  • Secure Command Line Interface (CLI): management with SSHv1/SSHv2
  • IP/Port/MAC based access control

    IPv6 Support:
  • IPv6 Dual IPv4/IPv6
  • Multicast Listener Discovery (MLD) Snooping
  • IPv6 ACL
  • IPv6 neighbor discovery (ND)
  • Path maximum transmission unit (MTU) discovery
  • Internet Control Message Protocol (ICMP) version 6
  • TCPv6/UDPv6
  • IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP

    Management:
  • Web-based GUI
  • Command Line Interface (CLI) through console port, telnet
  • SNMPv1/v2c/v3: Trap/Inform, RMON (1,2,3,9 groups)
  • SDM Template
  • DHCP/BOOTP Client
  • 802.1ab LLDP/LLDP-MED
  • DHCP Auto Install
  • CPU Monitoring
  • Cable Diagnostics
  • EEE
  • Password Recovery
  • SNTP
  • System Log
  • Dual Image, Dual Configuration

    MIBs:
  • MIB II (RFC1213)
  • Interface MIB (RFC2233)
  • Ethernet Interface MIB (RFC1643)
  • Bridge MIB (RFC1493)
  • P/Q-Bridge MIB (RFC2674)
  • RMON MIB (RFC2819)
  • RMON2 MIB (RFC2021)
  • Radius Accounting Client MIB (RFC2620)
  • Radius Authentication Client MIB (RFC2618)
  • Remote Ping, Traceroute MIB (RFC2925)
  • Support TP-Link private MIBs





Features

Brand:
TP-Link
Color:
Black
Conditions:
New
Warranty:
3 Years
