Home Networking Sensor Stego 267072 External Sensor - 6.56Feet

Stego 267072 External Sensor - 6.56Feet


Brand:

Specifications

   Product Details:
  • 100% brand new from factory and high quality.
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • Brand: Stego
  • Model: 267072
   Specification:
  • Heating Element: High performance cartridge
  • Overheat Protection: With automatic reset and second-tier one shot fuse
  • to protect against overheating in case of fan failure
  • Heater Body: Extruded Aluminium Profile
  • Axial Fan, Ball Bearing: Service life 50,000 h at +77 °F (+25 °C)
  • Air Flow, Free Blowing: 94 cfm (160 m³/h)
  • Connection:
  • 2-pole „Push-In“ connection clamp stranded wire1
  • AWG 16
  • (1.5 mm²) with strain relief; max. AWG 12 (2.5 mm²)
  • Housing: Plastic, UL 94V-0, black
  • Mounting: Clip for 35 mm DIN rail, EN 60715 or M6 screws and washers
  • (not included), torque 2 Nm max.
  • Mounting Position: Vertical airflow (air outlet up)
  • Dimensions: 3.9 x 6.6 x 7.0" (99 x 168 x 179 mm)
  • Operating Temperature: -4 to +167 °F (-20 to +75 °C)
  • Storage Temperature: -40 to +176 °F (-40 to +80 °C)
  • Operating / Storage Humidity: Max. 90 % RH (non-condensing)
  • Protection Type / Protection class: IP20 / II (double insulated)
  • Approvals: UL File No. E234324, VDE, EAC



Features

Brand:
Stego
Conditions:
New
Warranty:
No Warranty
