StarTech ST1000SPEX43 4-Port Gigabit Ethernet PCIe Card

Brand:

StarTech ST1000SPEX43 adds four RJ-45 Gigabit Ethernet ports through a PCI Express x4 interface. With Realtek RTL8111G, 10/100/1000Base-T support and TAA compliance, it suits servers, workstations and enterprise systems.

OVERVIEW

  • StarTech.com ST1000SPEX43 is a multi-port PCIe Ethernet expansion card designed for organisations that need four wired network connections from one add-in card. Its Realtek RTL8111G chipset and 10/100/1000Base-T support provide practical Gigabit connectivity for servers, workstations and computers. The TAA-compliant design positions it for professional and government IT deployments.
  • Compatibility / Model Compare: ST1000SPEX43 uses PCIe x4 and provides four RJ-45 Gigabit ports.

USE CASES

  • Add four Gigabit ports to compatible enterprise servers
  • Expand wired connectivity on professional workstations
  • Support multi-network computer deployments with one card
  • Upgrade systems requiring additional RJ-45 Ethernet ports
  • Connect servers to multiple compatible Ethernet networks
  • Deploy multi-port NICs in government IT environments
  • Provide Gigabit connectivity for Linux-based systems
  • Expand network interfaces on Windows Server systems
  • Support enterprise workstation network segmentation
  • Add copper Ethernet ports to PCIe-enabled computers
  • Upgrade legacy systems with additional network interfaces
  • Build flexible multi-port connectivity for IT infrastructure

KEY FEATURES

  • Adds four Gigabit Ethernet ports to compatible systems
  • Supports 10/100/1000Base-T wired network connectivity
  • Realtek RTL8111G chipset supports dependable Ethernet operation
  • PCI Express x4 interface enables multi-port network expansion
  • Four RJ-45 ports simplify multi-network system deployment
  • Supports computers, servers and professional workstations
  • Compatible with Windows and Windows Server environments
  • Supports specified Linux kernel versions for deployment flexibility
  • TAA compliance supports eligible government procurement
  • Plug-in card design simplifies internal network expansion
  • Up to 1.95 Gbps maximum specified data transfer rate
  • Compact form factor suits PCIe-based infrastructure upgrades

TECHNICAL SPECIFICATIONS

  • Brand: StarTech.com
  • Model: ST1000SPEX43
  • Product Type: 4-Port Gigabit Ethernet PCIe Network Card
  • Warranty: 2 Years
  • UPC Code: 65030862448
  • Chipset Model: RTL8111G
  • Host Interface: PCI Express x4
  • Number of Network Ports: 4
  • Network Port Type: RJ-45
  • Network Technology: 10/100/1000Base-T
  • Supported Media: Twisted Pair
  • Maximum Data Transfer Rate: 1.95 Gbps
  • Form Factor: Plug-in Card
  • Device Supported: Computer, Server, Workstation
  • Supported Operating Systems: Windows, Windows Server, Linux
  • Windows Support: Windows XP, 7, 8, 8.1, 10
  • Windows Server Support: 2003, 2012, 2016, 2019
  • Linux Support: Kernel 2.4.x to 4.11.x LTS
  • Height: 17.8 mm
  • Width: 119.4 mm
  • Depth: 137.2 mm
  • TAA Compliance: Yes
  • Environmentally Friendly: Yes
  • Compatibility: PCIe x4; 4 × RJ-45; 10/100/1000Base-T

WHY CHOOSE THIS PRODUCT?

  • Four network interfaces: Adds four RJ-45 Ethernet ports through one PCIe card, reducing the need for multiple expansion cards.
  • Gigabit Ethernet support: 10/100/1000Base-T compatibility supports network environments requiring standard copper Gigabit connectivity.
  • Practical server expansion: Designed for computers, servers and workstations that require additional wired network interfaces.
  • Established chipset platform: The Realtek RTL8111G chipset provides the specified hardware foundation for the card's Ethernet functionality.
  • Flexible OS deployment: Support for specified Windows, Windows Server and Linux versions helps accommodate existing IT environments.
  • Government procurement suitability: TAA compliance supports deployments where compliant technology is part of procurement requirements.
  • Efficient infrastructure upgrade: A single four-port adapter can expand network connectivity without replacing the host system.
