Home Networking Transceiver StarTech.com SFP+ 10GBASE-SR LC Duplex Transceiver Module

StarTech.com SFP+ 10GBASE-SR LC Duplex Transceiver Module

Brand:

StarTech.com SFP10GSRST is a 10GbE SFP+ multimode fiber transceiver designed for 10GBASE-SR networking. It uses an 850nm wavelength, LC duplex connector and supports transmission up to 300m (984ft.). The module is programmed and tested for Cisco SFP-10G-SR compatibility and supports DDM and hot-swappable installation, making it suitable for 10GbE switch and router upgrades.

OVERVIEW

  • The SFP10GSRST is a 10Gbps 10GBASE-SR SFP+ optical transceiver for multimode fiber networks, with LC duplex connectivity and up to 300m reach. It is aimed at network administrators upgrading switches, routers and fiber links to 10GbE. Compatibility: Cisco SFP-10G-SR compatible and works with MSA-compliant equipment accepting uncoded modules. Compare: Choose the correct OEM-coded StarTech module for your host platform.

USE CASES

  • 10GbE switch uplinks – Adds 10Gbps optical connectivity for high-throughput switch-to-switch links.
  • Data center interconnects – Provides multimode fiber connectivity for short-range data center network links up to 300m.
  • Server-to-switch connectivity – Enables compatible SFP+ server network adapters to connect over LC duplex multimode fiber.
  • Network expansion – Adds an additional 10GbE optical port without replacing an existing switch or router.
  • Fiber link replacement – Provides a replacement option for compatible 10GBASE-SR transceiver deployments.
  • Cisco network upgrades – Designed and tested for compatibility with Cisco SFP-10G-SR platforms, including listed Cisco switch and router families.
  • Enterprise LAN backbone links – Supports 10GbE multimode fiber connections between network infrastructure devices.
  • Short-distance high-speed fiber deployments – The 300m maximum transfer distance makes it suitable for many building and data-center fiber runs.

KEY FEATURES

  • 10GBASE-SR support – Provides up to 10Gbps connectivity for high-bandwidth Ethernet networking.
  • Multimode fiber operation – Uses MMF cabling for short-range 10GbE infrastructure, helping suit data-center and enterprise LAN deployments.
  • 300m maximum reach – Supports fiber links up to 300m (984ft.), providing useful coverage for short-to-medium data-center connections.
  • 850nm wavelength – Uses the 850nm optical wavelength specified for the 10GBASE-SR implementation.
  • LC duplex connector – Provides a standard LC duplex fiber interface for straightforward connection to compatible multimode fiber infrastructure.
  • Digital Diagnostic Monitoring – DDM provides transceiver-status information that can be used by compatible network-management systems.
  • Hot-swappable design – Allows compatible equipment to accept module installation or replacement without requiring a full network-device shutdown.
  • Cisco SFP-10G-SR compatibility – Programmed and tested for Cisco-compatible deployment, helping simplify replacement and expansion of supported Cisco equipment.
  • MSA-compliant equipment support – StarTech.com states that the module also works with MSA-compliant switches and routers that accept uncoded modules.
  • Lifetime warranty – StarTech.com backs its SFP/SFP+ transceiver modules with a lifetime warranty, supporting long-term procurement value.

TECHNICAL SPECIFICATIONS

  • Brand: StarTech.com
  • Product ID / SKU: SFP10GSRST
  • Product Type: SFP+ Fiber Optic Transceiver
  • Network Standard: IEEE 802.3ae 10GBASE-SR
  • Maximum Data Rate: 10 Gbps
  • Fiber Type: Multimode Fiber (MMF)
  • Wavelength: 850nm
  • Maximum Transfer Distance: 300m / 984ft.
  • Connector: LC Duplex
  • Host Interface: SFP+ Slot
  • DDM: Yes
  • Hot-Swappable: Yes
  • Power Consumption: Less than 1.2W
  • MTBF: 1,967,709 hours
  • Compatible Brand: Cisco
  • Compatibility: Cisco SFP-10G-SR compatible; MSA-compliant equipment accepting uncoded modules
  • Network Compatibility: 10 Gbps
  • Product Height: 0.5in / 1.2cm
  • Product Length: 2.6in / 65mm
  • Product Width: 0.6in / 1.4cm
  • Product Weight: 2.5oz / 72g
  • Package Quantity: 1
  • Material: Steel

Why Choose This Product?

  • 10GbE performance – Provides 10Gbps optical connectivity for bandwidth-intensive enterprise network links.
  • 300m multimode reach – Covers fiber runs up to 984ft., making it practical for many data-center and enterprise LAN applications.
  • Cisco-compatible option – Programmed and tested for Cisco SFP-10G-SR compatibility, reducing deployment uncertainty on supported Cisco equipment.
  • DDM visibility – Provides diagnostic information that can help network teams monitor transceiver status through compatible management systems.
  • Hot-swappable installation – Supports faster module replacement or upgrades on compatible equipment without requiring a complete device shutdown.
  • Low power consumption – StarTech.com specifies less than 1.2W, helping limit optical-module power draw.
  • Procurement-friendly replacement – A single-module package provides a practical option for targeted 10GbE link expansion or replacement.
  • Lifetime warranty – Adds long-term product coverage for infrastructure teams managing network optics. a
