StarTech.com MSTDP124DP 4-Port DisplayPort 1.2 MST Hub

• Brand: StarTech.com
• Product ID: MSTDP124DP
• Product Type: Active DisplayPort MST Hub
• Input: 1 × DisplayPort 1.2
• Outputs: 4 × DisplayPort 1.2
• Maximum Displays: 4
• MST Bandwidth: 21.6Gbps shared
• Maximum Digital Resolution: 3840 × 2160 at 30Hz
• Quad Display Configuration: 1920 × 1080 at 60Hz
• Supported Resolutions: 1024×768, 1280×720, 1920×1080, 1920×1200, 2560×1440, 2560×1600, 3840×2160 @30Hz
• Audio: DisplayPort 5.1-channel audio
• HDR: No
• Active/Passive: Active
• Chipset MegaChips: STDP4320
• DisplayPort Version: 1.2
• Maximum Display Cable Distance: 2m / 6.6ft
• Wide Screen Support: Yes
• Input Connector: 1 × DisplayPort
• Output Connectors: 4 × DisplayPort
• Power Source: AC adapter
• Input Voltage: 100–240V AC
• Input Current: 0.5A
• Output Voltage: 5V DC
• Output Current: 3A
• Power Consumption: 15W
• Built-in Cable Length: 190mm / 7.5in
• Enclosure Material: Plastic
• Color: Black
• Product Dimensions: 300 × 105 × 15mm
• Operating Temperature: 0°C to 45°C
• Storage Temperature: -20°C to 70°C
• Compatibility: DP 1.2 MST Windows systems
• macOS: Not compatible
• Drivers: Not required

Why Choose This Product?

• Four-display expansion: Adds substantial screen capacity from one compatible DisplayPort output.
• Independent desktop support: Lets users organize different applications across separate monitors.
• Quad 1080p at 60Hz: Makes the hub particularly suitable for everyday business and monitoring workloads.
• 4K capability: Supports Ultra HD resolutions for compatible high-resolution deployments.
• No driver installation: Simplifies rollout across supported Windows workstations.
• External power included: Provides the dedicated power required for reliable MST operation.
• Flexible display connectivity: DisplayPort adapters can extend compatibility to HDMI, DVI and VGA displays.
• Clear deployment requirements: Buyers can validate DP 1.2 MST, GPU limits and bandwidth before procurement, reducing compatibility-related deployment issues.
