StarTech DP2VGAMM6B DisplayPort to VGA Active Cable 6ft

• Connecting DisplayPort desktops to existing VGA monitors
• Connecting business laptops to VGA projectors
• Extending the useful life of legacy office displays
• Conference room and boardroom presentation systems
• Classroom and training-room display connectivity
• Workstation refreshes where VGA displays remain in service
• Secondary-display installations using VGA monitors
• IT replacement stock for legacy display infrastructure
• Corporate office and branch-site technology upgrades
• Connecting DisplayPort workstations to VGA-compatible equipment

• Active digital-to-analog DisplayPort to VGA conversion
• DisplayPort 1.2 input with HBR2 support
• Supports resolutions up to 1920x1200 or 1080p
• Supports 1080p output at 60Hz
• EDID and DDC pass-through for source-display communication
• 6ft or 1.8m integrated cable design
• Latching DisplayPort connector for secure host connection
• Screw-locking VGA connection helps prevent accidental disconnection
• Integrated converter chip reduces cable clutter
• Supports one VGA display
• No software or driver installation required
• Compatible with DisplayPort and DP++ sources
• Suitable for desktops, laptops, workstations, SFF PCs, and docking stations
• OS-independent operation

• Brand: StarTech.com
• Part Number: DP2VGAMM6B
• Product Type: DisplayPort to VGA Adapter Cable
• Adapter Type: Active
• AV Input: DisplayPort 1.2
• AV Output: VGA
• DisplayPort Standard: DisplayPort 1.2 HBR2
• Connector 1: DisplayPort
• Connector 2: VGA
• Number of Displays: 1
• Maximum Analog Resolution: 1920x1200 / 1080p
• Maximum Digital Resolution: 1920x1200 / 1080p
• Maximum Supported Refresh Rate: 60Hz
• Cable Length: 1828.8mm / 6ft
• Product Length: 1840mm / 72.4in
• Product Width: 35mm / 1.4in
• Product Height: 15mm / 0.6in
• Product Weight: 103.7g / 3.7oz
• Audio Support: No
• HDR Support: No
• Chipset: Analogix 9832
• MTBF: 1,449,804 hours
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -10°C to 70°C
• Humidity: 40% to 85% RH
• Color: Black
• Package Quantity: 1

WHY CHOOSE THIS PRODUCT?

• Organizations choose the DP2VGAMM6B when modern DisplayPort equipment must remain compatible with existing VGA displays or projectors. Its active conversion, 6ft integrated design, 1080p/1920x1200 support, EDID/DDC pass-through, and secure latching connectors make it more deployment-ready than a basic passive adapter. For procurement teams, it can reduce replacement pressure on compatible legacy displays while supporting workstation refreshes, presentation environments, and phased infrastructure modernization.
