Home Networking Power Simply45 S45-1150 Cat 6 STP Shielded External Ground RJ45 Standard Modular Plug with Bar45 (50-Piece Jar)- Silver

Simply45 S45-1150 Cat 6 STP Shielded External Ground RJ45 Standard Modular Plug with Bar45 (50-Piece Jar)- Silver


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • Lifetime Warranty
  • Brand: Simply45
  • Model: S45-1150

    Key Features
  • Cat 6 Shielded RJ45 Modular Plug
  • External Ground
  • Supports Solid LAN Cables
  • Gold-Plated 3-Prong Pins
  • Bar45 Load Bar
  • Green Tinted
  • Standard Plug Design
  • PoE/PoH Rated

    Specifications
    General
  • Type: RJ45 Male
  • Quantity: 50
  • Contact Plating: 50 µ Gold /100 µ Nickel
  • Contact Material: Bronze
  • Shielded: Yes
  • Conductor Diameter: 0" / 1.2 mm
  • Contact Resistance: 20 milliohms

    Compatibility
  • Supported Cable Diameter: 0.3" / 8 mm
  • Wire Gauge Supported: 23 to 23 AWG
  • Cable Types Supported: Solid, Stranded
  • Networking Type: Cat 6

    Physical
  • Plug Material: Polycarbonate
  • Compliance: RoHS, UL, FCC
  • Flame Resistance Rating: UL94V-0
  • Mating Cycles: 2000
  • Operating Temperature: -40 to 158°F / -40 to 70°C

    Packaging Info
  • Package Weight: 0.475 lb
  • Box Dimensions (LxWxH): 3.9 x 3.7 x 3.25"

Features

Brand:
Simply45
Color:
Silver
Conditions:
New
GTIN, UPC, EAN, JAN or ISBN:
817777017762
Warranty:
Lifetime
