Schneider Electric LRD350 TeSys Deca Contactor (Black)


Specifications

      Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Schneider Electric
  • Model: LRD350
  • Color: Black
     Specifications:
      Main:
  • Range: TeSys
  • Product or component type: Differential thermal overload relay
  • Device short name: LRD
  • Relay application: Motor protection
  • Rated operational voltage: 690 V AC 0...400 Hz for power circuit conforming to IEC 60947-4-1
  • Tripping threshold: 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1
  • Auxiliary contact composition: 1 NO + 1 NC
  • Conventional free air thermal current: 5 A for signalling circuit
      Permissible current:
  • 3 A at 120 V AC-15 for signalling circuit
  • 0.22 A at 125 V DC-13 for signalling circuit
      Associated fuse rating:
  • 4 A gG for signalling circuit
  • 4 A BS for signalling circuit
  • Rated impulse withstand voltage: 6 kV
  • Phase failure sensitivity: Tripping current 130 % of Ir on two phase, the last one at 0
      Control type:
  • Red push-button: stop
  • Blue push-button: reset
  • Temperature compensation: -20…60 °C
      Environment:
  • Climatic withstand: Conforming to IACS E10
  • IP degree of protection: IP20 conforming to IEC 60529
  • Ambient air temperature for operation: -20…60 °C without derating conforming to IEC 60947-4-1
  • Ambient air temperature for storage: -60…70 °C





Features

Brand:
Schneider Electric
Color:
Black
Conditions:
New
Warranty:
1 Year
