Home Networking Power Auto Transfer SwitchNew Schneider Electric LC1K0601B7 TeSys D Contactor (Black)

Schneider Electric LC1K0601B7 TeSys D Contactor (Black)


Specifications

      Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Schneider Electric
  • Model: LC1K0601B7
  • Color: Black
      Specifications:
      Main:
  • Range of product: TeSys Deca
  • Product or component type: Contactor
  • Device short name: LC1K
  • Device application: Control
  • Contactor application: Motor control
  • Poles description: 3P
  • Rated operational voltage:
  • Power circuit: <= 690 V AC <= 400 Hz
  • Signalling circuit: <= 690 V AC <= 400 Hz
      Rated operational current:
  • 6 A (at <60 °C) at <= 440 V AC AC-3 for power circuit
  • 6 A (at <60 °C) at <= 440 V AC AC-3e for power circuit
  • Control circuit voltage: 24 V AC 50/60 Hz
  • Pole contact composition: 3 NO
  • Contact compatibility: M14
  • Protective cover: With
  • Conventional free air thermal current: 200 A (at 60 °C) for power circuit
  • Irms rated making capacity: 1260 A at 440 V for power circuit conforming to IEC 60947
  • Rated breaking capacity: 1100 A at 440 V for power circuit conforming to IEC 60947
      Associated fuse rating:
  • 25 A gG at <= 440 V for power circuit
  • 25 A aM for power circuit
  • 10 A gG for signalling circuit conforming to IEC 60947
  • 10 A gG for signalling circuit conforming to VDE 0660
  • Average impedance: 3 mOhm - Ith 16 A 50 Hz for power circuit
  • Power dissipation per pole: 24 W AC-1
  • Rated impulse withstand voltage: 8 kV conforming to IEC 60947




Features

Brand:
Schneider Electric
Color:
Black
Conditions:
New
Warranty:
1 Year
