Home Networking Router, Security, NPB Routers Prolink DL-7302 4G LTE CAT4 Wi-Fi Home Router with Sim card slot (Comes in 4x LAN, 1xWAN, 1x USB ports)

Prolink DL-7302 4G LTE CAT4 Wi-Fi Home Router with Sim card slot (Comes in 4x LAN, 1xWAN, 1x USB ports)


Brand:

Specifications

   Product details:
  • Life Time Warranty
  • Brand: Prolink
  • Model: DL-7302
   Specifications:
  • LTE Category: CAT.4 (3GPP E-UTRA Release 10)
   4G FDD Bands:
  • B2/B4/B5/B12/B13/ B14/B66/B71
  • Download max 150Mbps / Upload max 50Mbps
   3G Bands:
  • B2/B4/B5
  • DC-HSDPA: DL Max 42Mbps
  • HSUPA: UL Max 5.76Mbps
  • WCDMA: DL 384Kbps / UL 384Kbps
  • Bandwidth: 1.4/3/5/10/15/20MHz
  • Support Antenna: DL MIMO, supports Rx-diversity (Except LTE B2)
  • Temperature: Working: -40°C ~ +80°C
  • Working Area: North America
   Certification:
  • GCF / FCC / IC / PTCRB
  • AT&T / Verizon /T-Mobile / Telus /Bell
  • CPU: Qualcomm Atheros QCA9531
  • Frequency: 650MHz
  • Memory: DDR2 RAM 128MB
  • Flash: SPI FLASH 16MB
  • SIM card slot: Double Nano-SIM Cards (12.3×8.8mm)
  • WAN/LAN Port: 10/100Mbps on PoE adapter
  • Indicator: System / Wi-Fi / SIM1 / SIM2
  • Temperature: Working: -40 to +80°C
  • Storage: -50 to +90°C
  • Humidity: 10%~90% RH
  • Measurement: Router 230x175x70mm / 980g
  • Connector: SMA Male (Not RP)
  • Polarization: Vertical
  • Impedance: 50 O
  • Max Input power: 10 Watt
  • Temperature: Working: -0° to 50° Celsius



Features

Brand:
Prolink
Warranty:
Life time warranty
