PCE Electric 2242-6 CEE Industrial Mobile Connector


Brand:
PCE

Specifications

      Product Details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: PCE
  • Model: 2242-6
  • Color: Red
      Specification:
  • Current Rating: 32 Amp
  • Pin Configuration: 3pH+E 415v 4Pin
  • Voltage Rating: 415v
  • IP Rating: IP67 Waterproof
  • International Standard: IEC 60309 1 & 2
  • Application Directives: RoHS
  • Terminal Cross Section: 2.5-6mm
  • Temperature range: -25 °C to +80 °C
  • Clock-position: 6h
      Details:
  • PCE has a dynamic range of CEE Connectors ranging from 16A to 125A, 3 to 5 Pole and available in IP44 or IP67 versions.  A robust design that can challenge harsh environments. Quick and easy assembly that saves time and energy.
  • High Thermal Stability(self-extinguishing)
  • High weathering resistance
  • UV-resistance according ISO 4892-2
  • Very good chemical resistance to various chemicals
  • Free from cadmium and halogen

Features

Brand:
PCE
Color:
Black
Conditions:
New
Warranty:
1 Year
