HPE ProLiant ML30 Gen10 Tower Server P16928-AA1 16GB RAM

Brand:
HPE

The HPE ProLiant ML30 Gen10 Server P16928-AA1 is a compact 4U tower server designed for small businesses and branch offices. It features an Intel Xeon E-2224 quad-core processor, 16GB DDR4 UDIMM memory and four Large Form Factor (LFF) drive bays. Integrated HPE Smart Array S100i SATA storage control and HPE Integrated Lights-Out 5 (iLO 5) management support server administration and storage configuration. The system is suitable for file sharing, business applications, data storage and selected entry-level virtualization workloads. HPE has retired this model, making it particularly relevant when assessing existing infrastructure or sourcing hardware for legacy environments.

OVERVIEW

  • The HPE ProLiant ML30 Gen10 P16928-AA1 is a single-socket tower server for small-office and branch-office IT environments. Its Intel Xeon E-2224 processor operates at a 3.4GHz base frequency, with turbo speeds up to 4.6GHz. The supplied configuration includes 16GB DDR4 UDIMM memory, with support for up to 64GB across four DIMM slots. Four LFF drive bays provide storage configuration options, while the embedded HPE Smart Array S100i software controller supports SATA storage. HPE iLO 5 provides integrated server management.

USE CASES

  • Small Business IT Infrastructure: Host supported business services in a small-office environment.
  • File and Print Services: Configure the server for file sharing and supported print services.
  • Business Application Hosting: Run compatible business applications according to their resource requirements.
  • Business Data Storage: Configure supported SATA drives in the available LFF bays.
  • Branch Office Deployment: Provide local server resources for remote offices.
  • Backup Environments: Evaluate the platform for compatible backup software and storage configurations.
  • Collaboration Services: Host supported collaboration applications where the processor and memory capacity are suitable.
  • Entry-Level Virtualization: Assess for lightweight virtualization after checking workload, memory and software requirements.
  • Education IT Infrastructure: Support compatible administrative or departmental services in educational environments.
  • Accounting and ERP Applications: Run compatible applications after verifying operating system and application requirements.
  • Legacy Server Replacement Planning: Assess the model for continuity with existing compatible infrastructure, considering its retired lifecycle status.

KEY FEATURES

  • Intel Xeon E-2224 Processor: Provides four CPU cores with a 3.4GHz base frequency and up to 4.6GHz turbo frequency for supported business workloads.
  • 16GB DDR4 UDIMM Memory: Includes 16GB installed memory, with platform support for up to 64GB across four DIMM slots.
  • Four LFF Drive Bays: Provides four Large Form Factor drive bays for supported storage configurations.
  • Embedded HPE Smart Array S100i Controller: Supports SATA storage management through the embedded software controller.
  • HPE iLO 5 Management: Provides integrated remote server management capabilities for supported administration tasks.
  • 4U Tower Design: Uses a tower chassis suited to office and branch environments, with rack-mounting possible using an optional sliding shelf kit.
  • Single-Socket Platform: Uses a single-processor configuration based on the Intel Xeon E-2224.
  • Expandable Memory: Supports memory expansion up to 64GB across four DIMM slots.
  • Business Server Applications: Suitable for file sharing, business applications and selected small-office infrastructure workloads.

TECHNICAL SPECIFICATIONS

  • Brand: Hewlett Packard Enterprise (HPE)

  • Product Series: HPE ProLiant ML30 Gen10
  • Model: P16928-AA1
  • Product Type: Tower Server
  • Form Factor: 4U Tower
  • Processor: Intel Xeon E-2224
  • Processor Cores: 4
  • Processor Base Frequency: 3.4GHz
  • Maximum Turbo Frequency: Up to 4.6GHz
  • Installed Memory: 16GB
  • Memory Type: DDR4 UDIMM
  • Maximum Memory Capacity: Up to 64GB
  • Memory Slots: 4 DIMM slots
  • Drive Bays: 4 × LFF
  • Storage Controller: Embedded HPE Smart Array S100i software controller
  • Storage Interface: SATA
  • Server Management: HPE Integrated Lights-Out 5 (iLO 5)
  • Rack-Mounting: Supported with optional sliding shelf kit

WHY CHOOSE THIS PRODUCT?

  • Business Workload Support: The Xeon E-2224 processor and 16GB installed memory provide a foundation for supported small-business server applications.
  • Flexible Storage Configuration: Four LFF drive bays allow buyers to plan supported SATA storage configurations for business data.
  • Memory Expansion: Platform support for up to 64GB of memory provides room for supported memory upgrades.
  • Integrated Management: HPE iLO 5 supports remote administration and server management.
  • Office-Friendly Tower Design: The 4U tower format can suit locations without a dedicated rack, subject to installation requirements.
