NDR-240-48 DIN Rail 240W 48V 5A W/PFC Function Power Supply


Brand:
No Brand

Specifications

      Product Details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • Model: NDR-240-48
      Specification:
  • Weight: 2.27 pounds
  • Dimensions: 4.47 x 2.48 x 4.93 inches
      Features:
  • High efficiency up to 94%
  • Universal AC input / Full range (SDR-75/120/240/480);AC input 180~264VAC only (SDR-960)
  • Built-in active PFC function (SDR-120/240/480/960)
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35 / 7.5 or 15
  • UL508(industrial control equipment) approved
  • EN61000-6-2(EN50082-2) industrial immunity level
  • Built-in DC OK relay contact (except for SDR-75)
  • 150% peak load capability (SDR-75/120/240/480);130% peak load capability (SDR-960)
  • Current sharing up to 3840W (7+1) for SDR-480P;Current sharing up to 3840W (3+1) for SDR-960
  • Comply with GL (SDR-120/240/480);Comply with SEMI F47 (SDR-75/120/240/480)

Features

Brand:
No Brand
Conditions:
New
Warranty:
No Warranty
