Home Optics and Transceivers Juniper SRX-SFP-1GE-SX-ET Small Form Factor Pluggable 1000Base-SX Gigabit Ethernet Optical Transceiver (Silver)- 740-011613

Juniper SRX-SFP-1GE-SX-ET Small Form Factor Pluggable 1000Base-SX Gigabit Ethernet Optical Transceiver (Silver)- 740-011613


Brand:

Specifications

        Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Juniper
  • Model: SRX-SFP-1GE-SX-ET

    Technical Specifications:
  • Part Number: 740-011613
  • Speed: 1000 Mbps (Gigabit Ethernet)
  • Transceiver Type: SFP (Small Form-factor Pluggable)
  • Connector: Duplex LC (standard for fiber optic cables)
  • Monitoring: Digital Optical Monitoring (DOM) available
  • Signal Standard: 1000BASE-SX (Gigabit Ethernet over short-range multimode fiber)

    Optical Specifications:
  • Transmitter Wavelength: 850 nm (common for multimode fiber)

    Transmitter Output Power (per lane):
  • Minimum: –9.5 dBm
  • Maximum: –3 dBm

    Receiver Input Power (per lane):
  • Minimum: –21 dBm
  • Maximum: 0 dBm
  • Transmitter Fibers: Dual (two fibers, one for transmitting, one for receiving)

    Cable Type and Fiber Grades:
  • Cable Type: MMF (Multimode Fiber)
  • Core Sizes: 62.5 µm / 50 µm

    Fiber Grades:
  • FDDI (Fiber Distributed Data Interface) grade
  • OM1, OM2, OM3, OM4 (various standards for multimode fiber)

    Effective Modal Bandwidth (EMB) (MHz x km):
  • OM1: 160 MHz·km
  • OM2: 200 MHz·km
  • OM3: 400 MHz·km
  • OM4: 500 MHz·km
  • High-performance fiber grades like OM3 and OM4 enable longer distances.

    Distance (Maximum Reach):
  • OM1: 220 meters
  • OM2: 275 meters
  • OM3: 500 meters
  • OM4: 550 meters (best distance)

    Power Consumption:
  • Maximum: 1 W

    Temperature Range:
  • Operating Temperature: –10°C to 85°C
  • Storage Temperature: –40°C to 85°C



Features

Brand:
Juniper
Color:
Silver
Conditions:
New
Warranty:
1 Year
