Home Optics and Transceivers Juniper SFP-1GT13R15BX10-I SFP 1GE BiDir Tx 1310nm Rx 1550nm 10km Gigabit Ethernet Optical Transceiver (Silver)- 740-094029

Juniper SFP-1GT13R15BX10-I SFP 1GE BiDir Tx 1310nm Rx 1550nm 10km Gigabit Ethernet Optical Transceiver (Silver)- 740-094029


Brand:

Specifications

        Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Juniper
  • Model: SFP-1GT13R15BX10-I

    Technical Specifications:
  • Part Number: 740-094029
  • Product Type: Optical Transceiver (SFP)
  • Connector: Simplex LC
  • Transceiver Type: SFP
  • Transmitter Wavelength: 1260 nm to 1360 nm (range)
  • Receiver Wavelength: 1540 nm to 1560 nm (range)
  • Distance: 10 km (on Single Mode Fiber, SMF)
  • Cable Type: SMF (Single-Mode Fiber)
  • Core Size/Cladding: 9/125 µm
  • Signaling Rate (per lane): 1.25 GBd ± 100 ppm
  • Transmitter Output Power (each lane): -9 dBm (min), -3 dBm (max)
  • Receiver Input Power (each lane): -20 dBm (min), -3 dBm (max)
  • Receiver Sensitivity (OMA, max): -18.7 dBm
  • Stressed Receiver Sensitivity (OMA, max): -14.6 dBm

    Diagnostic Monitoring:
  • Digital Optical Monitoring (DOM): Available, which includes:
  • Transceiver Temperature
  • Transceiver Supply Voltage
  • Transmitter Bias Current
  • Transmitter Output Power
  • Receiver Optical Power

    Environmental and Physical Specifications:
  • Operating Temperature Range: -40°C to 85°C
  • Storage Temperature Range: -40°C to 85°C
  • Max Power Consumption: 1.0 W
  • Weight: 75 grams

    Dimensions:
  • Height: 8.5 mm
  • Width: 13.4 mm
  • Depth: 56.5 mm
    740-094029
    SFP-1GT13R15BX10-I
    Juniper Transceiver
    Transceiver

Features

Brand:
Juniper
Color:
Silver
Conditions:
New
Warranty:
1 Year
