Home WDM, OTN & PON PON Networks PON Transceivers JD118B HPE H3C Compatible 1000BASE-SX SFP 850nm 550m DOM Duplex LC MMF Transceiver Module For HPE FlexNetwork And FlexFabric Switch Series

JD118B HPE H3C Compatible 1000BASE-SX SFP 850nm 550m DOM Duplex LC MMF Transceiver Module For HPE FlexNetwork And FlexFabric Switch Series


Brand:

Specifications

   Product Details:
  • 1 Year Warranty
  • Brand: No Brand
  • Model: JD118B
   Specification:
  • Type: HP X120 1G SFP LC SX Transceiver
  • Ports: 1 LC 1000BASE-SX port
  • Connector Type: LC
  • Wavelength: 850 nm
  • Cabling Distance (Maximum):
  • FDDI Grade Distance: 220m
  • OM1: 275m
  • OM2: 500m
  • OM3: Not Specified by standard
  • Cable Length: up to 550m
  • Fiber Type: Multi Mode
  • Power Consumption Typical: 0.8 W
  • Power Consumption Maximum: 1.0 W
  • Dimensions: 2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)
  • Weight: 0.04 lb.



Features

Brand:
No Brand
Conditions:
New
Warranty:
1 Year
