Home Networking Power InWin P Series P65 650W SECC ATX12V EPS12V APFC 80 PLUS Gold Certified Full Modular Power Supply (Black)

InWin P Series P65 650W SECC ATX12V EPS12V APFC 80 PLUS Gold Certified Full Modular Power Supply (Black)


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: InWin
  • Model: P65
  • Color: Black
       Specification:
  • Type: ATX12V / EPS12V
  • Maximum Power: 650 W
  • Fans: 135mm FDB Fan
  • PFC: Active
  • Main Connector: 20+4Pin
  • +12V Rails: Single
  • PCI-Express Connector: 4 x 6+2-Pin
  • SATA Power Connector: 9
  • Modular: Full Modular
  • Efficiency: > 90%
  • Energy-Efficient: 80 PLUS GOLD Certified
  • Protection: OCP/ OVP/ UVP/ SCP/ OTP/ OPP
  • Input Voltage: 100 - 240 V
  • Input Frequency Range: 50/60 Hz
  • Input Current: 10A
  • Output: +3.3V@22A, +5V@22A, +12V@54.2A, -12V@0.3A, +5VSB@3A
  • MTBF: >100,000 Hours
  • Approvals: cTUVus/ TUV/ CB/ BSMI/ CE/ FCC/ EAC/ CCC/ RCM
  • Max PSU Length: 160 mm
        Connectors:
  • 1 x 20+4 Pin Motherboard
  • 1 x 8 (4+4) Pin CPU
  • 4 x 8 (6+2) Pin PCI-E
  • 4 x 4 Pin Peripheral
  • 9 x SATA (90 Degree)
  • 1 x Floppy




Features

Brand:
InWin
Color:
Black
Conditions:
New
Warranty:
1 Year
