Home Networking Network Switches Extreme Brocade VDX6740-48 Switch | 48x 10GbE SFP+ Ports, Back-to-Front Airflow | For Virtualized & SAN Convergence (BR-VDX6740-48-R)

Extreme Brocade VDX6740-48 Switch | 48x 10GbE SFP+ Ports, Back-to-Front Airflow | For Virtualized & SAN Convergence (BR-VDX6740-48-R)


Brand:

Specifications

       Description
  • The BR-VDX6740-48-R is a high-performance, low-latency 1U data center switch equipped with 48 active 10GbE SFP ports and 4 QSFP uplink slots (licensed separately). With a 1.28Tbps switching capacity, 960Mpps forwarding rate, and ultra-low 850ns port-to-port latency, it's optimized for environments where speed and efficiency are critical
       Features
  • 48×10GbE SFP Ports (all active)
  • 4×40GbE QSFP Uplinks (license-activatable)
  • 1.28Tbps Switching Capacity
  • 960Mpps Packet Throughput
  • Low Latency: 850ns
  • 160,000 MAC Address Capacity
  • Back-to-Front Airflow (port-side exhaust)
  • N+1 Redundant Fans integrated into PSU
  • Dual Hot-Swappable AC PSUs – load sharing
  • Management Ports: RJ45 console, Gigabit management, USB 2.0
  • Dimensions: 1U form factor (43.99×4.32×40.99cm) – 8.66kg
       Specifications
  • Brand: Extreme
  • Model: BR-VDX6740-48-R
  • Switching Capacity: 1.28Tbps
  • Forwarding Rate: 960Mpps
  • Latency: 850ns
  • MAC Table Size: 160,000
  • Ports: 48×10GbE SFP + 4×40GbE QSFP
  • Cooling: Back-to-front airflow, N+1 redundant fan design
  • Power: Dual hot-swappable, load-sharing AC PSUs
  • Environmental Specs: Operates 0–40°C / 10–85% RH; Altitude to 3048m
       Ideal Use Cases
  • Leaf/Core Switch – Ideal for spine-leaf data center fabrics
  • High-Performance Aggregation – Connects dense server/storage racks
  • Latency-Sensitive Environments – High-frequency trading, HPC, real-time analytics
  • Virtualized & SAN Convergence – VCS fabric ready, with optional FCoE licensing
  • 10GbE Scaling – Ports on Demand (PoD) upgrades expand capacity to 64×10GbE
       Why This Switch?
  • High Port Density with scalable uplinks in a compact 1U chassis
  • Wire-Speed Processing ensures no bottlenecks in high-throughput scenarios
  • Low Latency supports performance-critical apps
  • Scalable & Redundant – Modular airflow, PSUs, and licensing allow growth
  • Certified & Compatible – Supports full L2/L3 features, QoS, VLAN, ACLs, multicast, IPv4/IPv6 protocols

Features

Brand:
Extreme
Conditions:
New
Warranty:
1 Year
