Home Networking Power EVGA 220-GA-0850-X3 SuperNOVA 850 GA, 80 Plus Gold 850W, Fully Modular, Eco Mode, Includes Power ON Self, Compact 150mm Size Power Supply

EVGA 220-GA-0850-X3 SuperNOVA 850 GA, 80 Plus Gold 850W, Fully Modular, Eco Mode, Includes Power ON Self, Compact 150mm Size Power Supply


Brand:

Specifications

   Product details:
  • 10 Years Warranty
  • Brand: EVGA
  • Model: 220-GA-0850-X3
   Specifications:
  • Type: ATX12V
  • Maximum Power: 850W
  • Fans: 135mm Double Ball Bearing Fan
  • Main Connector: 24Pin
  • +12V Rails: Single
  • PCI-Express Connector: 6 x 6+2-Pin
  • SATA Power Connector: 9
  • SLI: SLI Ready
  • CrossFire: CrossFire Ready
  • Modular: Full Modular
  • Energy-Efficient: 80 PLUS GOLD Certified
  • Over Voltage Protection: Yes
  • Input Voltage: 100 - 240 V
  • Input Frequency Range: 50/60 Hz
  • Input Current: 10 - 5 A
  • Output: +3.3V@20A, +5V@20A, +12V@70.8A, -12V@0.3A, +5VSB@3A
  • MTBF: >100,000 Hours
  • Approvals: TUV, CB, CE, FCC, RCM, cTUVus, CCC, WEEE, RoHS
  • Compliance with ErP Lot 3 2014
  • Dimensions: 3.39" x 5.91" x 5.91"
  • Max PSU Length: 150 mm
  • Weight: 7 lbs.
   Connectors:
  • 1 x 24 Pin ATX
  • 2 x 8pin(4+4) EPS (CPU)
  • 6 x 8pin(6+2) PCIe
  • 9 x SATA
  • 4 x Four-Pin Peripheral
  • 1 x Floppy


Features

Brand:
EVGA
Warranty:
10 Years
