Home Networking Power Elektro-Automatik EA-PS 9080-100 1U Modular Power Supply (White)

Elektro-Automatik EA-PS 9080-100 1U Modular Power Supply (White)


Specifications

  Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 1 Year Warranty
  • Brand: Elektro-Automatik
  • Model: EA-PS 9080-100 1U
  • Color: White
   Specification:
   DC Voltage:
  • Accuracy: <0.1% of rated value
  • Load regulation: 0-100% <0.05% of rated value
  • Line regulation: ±10% UAC <0.02% of rated value
  • Regulation: 10-100% load <2.2 ms
  • Rise time: 10-90% (CV) Max. 15 ms
   DC Current:
  • Accuracy: <0.2% of rated value
  • Load regulation: 1-100% UDC <0.15% of rated value
  • Line regulation: ±10% UAC <0.05% of rated value
   DC Power:
  • Accuracy: <1% of rated value
  • Overvoltage category: 2
  • Protection: OTP, OVP, OCP, OPP, PF
   Insulation:
  • AC input to enclosure: 2500 V DC
  • AC input to DC output: 2500 V DC
  • DC output to enclosure (PE) Negative: max. 400 V DC, positive: max. 400 V DC + output voltage
  • Degree of pollution: 2
  • Protection class: 1
  • Analog interface: Built in, 15 pole D-Sub (female)


Features

Brand:
Elektro-Automatik
Color:
White
Conditions:
New
Warranty:
1 Year
