Elektro-Automatik EA-PS 10500-10 2U Modular Power Supply (White)


Specifications

   Product details:
  • 1 Year Warranty
  • Brand: Elektro-Automatik
  • Model: EA-PS 10500-10 2U
   Specification:
  • No. of Slots / Outputs: 1Outputs
  • Output Power Max: 1.5kW
  • Power Supply Output Type: Programmable
  • Output Voltage Min: 0V
  • Output Voltage Max: 500V
  • Output Current Max: 10A
   Features:
  • Wide range input, 208VAC - 480VAC +10 % 3ph
  • Active power factor correction, typical 0.99
  • Power range from 0 - 1500W
  • Voltage range from 0 to 500VDC
  • Current range from 0 to 10A
  • Regulation mode CV, CC, CP with fast crossover
  • Digital regulation, high resolution with 16bit ADC & DACs, selection of speed: normal, fast, slow
  • Colour 5" TFT display with touch control and intuitive user interface
  • Galvanically isolated share-bus for parallel operation of all power classes in the 10000 series
  • Command languages and drivers: SCPI and Modbus, LabVIEW, IVI

Features

Brand:
Elektro-Automatik
Color:
White
Conditions:
New
Warranty:
1 Year
