DSS1NB32A220Q91A Feedthrough Capacitor, 22 pF, 100 V, 6 A, Radial, Through Hole, Electronic Components


Brand:
No Brand

Specifications

   Product details:
  • Brand: No Brand
  • Warranty: No Warranty
   Specifications
  • Shape: Lead
  • Length: 8.5mm
  • Length Tolerance: max.
  • Width: 3.5mm
  • Width Tolerance: max.
  • Thickness: 7.5mm
  • Thickness Tolerance: max.
  • Rated Current: 6A
  • Operating Temperature Range: -40 to 85
  • Mass(type): 0.45g
  • Number of Circuit: 1
  • Insulation Resistance(min.): 1000MO
  • Rated Voltage: 100Vdc
  • Withstanding Voltage: 250Vdc
  • Capacitance: 22pF
  • Capacitance Tolerance: ±10%
  • Structure/Shape: Small type beads inside(straight)
   Features
  • DSS1 series is a compact, high performance
  • lead type 3 terminal capacitor which can be
  • mounted in 2.54mm pitch.
  • Its three terminal structure enables nice
  • high frequency performance.
  • Wide capacitance variation enables flexible
  • selection for various noise frequencies.
  • High speed mounting is available with automatic
  • insertion machine.
