Home Networking D-Link DMC-810SC/E 10/100BASE-TX to 100BASE-FX (SC) Multi-Mode Fiber Media Converter - 2KM

D-Link DMC-810SC/E 10/100BASE-TX to 100BASE-FX (SC) Multi-Mode Fiber Media Converter - 2KM


Brand:

Specifications

   Product Overview:
  • The D-Link DMC-810SC/E is a Fast Ethernet fiber media converter designed to convert 10/100BASE-TX copper Ethernet signals into 100BASE-FX multi-mode fiber, enabling stable and long-distance network connectivity.

  • It supports multi-mode fiber transmission up to 2km, making it ideal for extending LAN connections across buildings, campuses, or industrial environments. The device includes 1 RJ45 Ethernet port and 1 SC fiber port, ensuring seamless integration with existing network infrastructure.
  • With features like auto-negotiation, auto MDI/MDIX, and IEEE 802.3x flow control, the DMC-810SC/E ensures efficient data transmission and simplified installation. It operates using store-and-forward switching, improving reliability and minimizing packet loss.
   Features:
  • Converts 10/100BASE-TX Ethernet to 100BASE-FX fiber
  • Supports multi-mode fiber up to 2km distance
  • SC fiber connector for secure and stable connection
  • Auto-negotiation for speed and duplex modes
  • Auto MDI/MDIX for easy plug-and-play setup
  • IEEE 802.3x flow control for reliable transmission
  • Store-and-forward architecture for efficient data handling
  • Standalone or chassis-based deployment
   Specifications:
  • Interface: 1 × RJ45 (10/100BASE-TX), 1 × SC (100BASE-FX)
  • Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Data Rate: 10/100 Mbps (Fast Ethernet)
  • Fiber Type: Multi-mode (50/125µm, 62.5/125µm)
  • Max Distance: Up to 2 km
  • Wavelength: 1300 nm
  • Duplex Mode: Half / Full Duplex
  • Power Supply: External adapter (5V/1A)
  • Power Consumption: Approx. 2.4W
  • Operating Temperature: 0°C to 40°C
   Ideal For:
  • Enterprise and campus network expansion
  • Building-to-building fiber connections
  • Industrial networking environments
  • Long-distance Ethernet extension
  • IT infrastructure and system integrators
   Why choose this Product?
  • Reliable 2km fiber connectivity for Fast Ethernet
  • Stable and interference-free transmission
  • Easy plug-and-play installation
  • Flexible deployment (standalone or rack chassis)
  • Trusted D-Link enterprise-grade solution


Features

Brand:
Dlink
Conditions:
New
Warranty:
Life time warranty
