Home Networking Power Customized 4 Fibers OM1/OM2 Multimode Indoor Tight-Buffered Multi-Fiber Breakout Cable (Orange)

Customized 4 Fibers OM1/OM2 Multimode Indoor Tight-Buffered Multi-Fiber Breakout Cable (Orange)


Brand:
No Brand

Specifications

      Product details:
  • 100% Brand New from Factory and High Quality
  • Economical Price
  • Sold and Shipped from Singapore (hence faster delivery, Easy to exchange)
  • 1 Year Warranty
      Specification:
  • Connector Type: LC/SC/ST/FC/LSH
  • Polish Type: UPC to UPC
  • Fiber Mode: OM1/OM2
  • Wavelength: 850/1300nm
  • Fiber Count: 4 Fibers
  • Cable Jacket: PVC/LSZH
  • Insertion Loss: =0.3 dB
  • Return Loss: =20 dB
  • Attenuation at 850nm: 3.0dB/km
  • Attenuation at 1300nm: 1.0dB/km
  • Fiber Grade: G.651 (OM1)/Bend Insensitive (OM2)
  • Minimum Bend Radius (mm): 20/10D (Dynamic/Static)
  • Breakout Diameter: 2.0/0.9mm
  • Trunk Diameter: 7.0-8.0mm/4.6-5.0mm
  • Breakout Type: 0.3m/0.5m Equal Breakout (Default)
  • Polarity: A (Tx) to B (Rx)
  • Operating Temperature: -40~75°C
  • Storage Temperature: -45~85°C

Features

Brand:
No Brand
Color:
Orange
Conditions:
New
Warranty:
1 Year
