Home Networking Power Customized 2-24 Fibers OS2 Single Mode LC/SC/FC/ST/LSH Industrial Armored Fiber Optic Pigtail - Black

Customized 2-24 Fibers OS2 Single Mode LC/SC/FC/ST/LSH Industrial Armored Fiber Optic Pigtail - Black


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, easy to exchange)

    Features:
  • TPU Jacket Features Water, Abrasion, Low-temperature Resistance
  • Helical Steel Armor Provides Additional Crush and Rodent Protection
  • Available with LC, SC, FC, ST, LSH Connectors
  • Customized 2-24 Fibers Pigtails Are Serialized
  • For Harsh Environments Including Building Sites, Industrial Networks, Roadworks
  • Operating & Storage Temperature Up to -40~80°C
  • Max. 600N Tensile Strength and Max. 3000N Crush Strength

    Specification:
  • Connector Type: LC/SC/FC/ST/LSH
  • Polish Type: UPC/APC
  • Fiber Count: 2/4/6/8/12/24
  • Cable Jacket: TPU (Thermoplastic Polyurethane)
  • Fiber Mode: OS2 9/125µm
  • Wavelength: 1310/1550nm
  • Attenuation at 1310nm: 0.36 dB/km
  • Attenuation at 1550nm: 0.22 dB/km
  • Min. Bend Radius (Fiber Cable): 20/10D (Dynamic/Static)
  • Fiber Grade: G.657.A2
  • Insertion Loss: =0.3dB
  • Return Loss: UPC=50dB, APC=60dB
  • Crush Resistance: 1000/3000 N/100mm (Long/Short Term)
  • Tensile Load: 200/600N (Long/Short Term)
  • Impact Resistance: 200 Impacts
  • Flex Resistance: 2000 Cycles
  • Trunk Diameter: 3.0-7.0mm
  • Breakout Diameter: 3.0mm (2~4 Fibers), 2.5mm (6~24 Fibers)
  • Operating Temperature: -40 to 80°C (-40 to 176?)
  • Storage Temperature: -40 to 80°C (-40 to 176?)







Features

Brand:
No Brand
Color:
Black
Conditions:
New
Warranty:
No Warranty
