Home Networking Power Cooler Master V750 Gold V2 750W 80 PLUS Gold Modular Power Supply (MPY-750V-AGBAG) - White

Cooler Master V750 Gold V2 750W 80 PLUS Gold Modular Power Supply (MPY-750V-AGBAG) - White


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange).
  • 1 Year Warranty
  • Brand: Cooler Master
  • Model: MPY-750V-AGBAG
  • Series:  V750

    Key Features
  • 750W Single +12V Rail
  • 135mm Cooling Fan
  • Modular Cables
  • ATX 12V v2.52
  • 90% Energy Efficiency Rating
  • 4 x PCIe Connectors
  • 12 x SATA Connectors
  • 4 x 4-Pin Peripheral Connectors
  • Semi-Fanless Mode
  • Comprehensive Protection

    Specifications
    Connectivity
  • Total Connectors: 1 x 24-Pin ATX Motherboard
  • 1 x 4+4-Pin EPS CPU
  • 1 x 8-Pin EPS CPU
  • 12 x 15-Pin SATA
  • 4 x 4-Pin Peripheral / Molex
  • 1 x 4-Pin Floppy
  • 4 x 6+2-Pin PCIe
  • Cable Design: Modular
  • PCIe Connector Distances: 21.7 Inches/ 550 mm
  • 4.7 Inches/ 120 mm
  • SATA Connector Distances: 19.7 Inches / 500 mm
  • 4.7 Inches / 120 mm
  • 4.7 Inches / 120 mm
  • 4.7 Inches / 120 mm
  • Peripheral Connector Distances: 19.7" / 500 mm
  • 4.7 Inches / 120 mm
  • 4.7 Inches / 120 mm
  • 4.7 Inches / 120 mm
  • Floppy Connector Distances: 4.7 Inches / 120 mm
  • ATX Connector Distance: 25.6 Inches / 650 mm
  • EPS Connector Distances: 25.6 Inches / 650 mm

    Electrical
  • Total Wattage: 750 W
  • Number of +12 V Rails: 1
  • Combined Power for +12 V: 750 W
  • Max Load for +12 V: 62.5 A
  • Combined Power for +3.3/+5 V: 120 W
  • Max Load for +3.3 V: 20 A
  • Max Load for +5 V: 20 A
  • Max Power for +5 Vsb: 15 W
  • Max Load for +5 Vsb: 3 A
  • Max Power for -12 V: 3.6 W
  • Max Load for -12 V: 0.3 A

    General
  • Efficiency Rating: 80 PLUS Gold
  • Active Power Factor Correction: Yes
  • Efficiency: 90%
  • Hold up Time: 17 ms
  • Power-Good Signal: 100 to 500 ms

    Cooling
  • Fan Size: 135 mm
  • Fan Speed: 1545 rpm
  • Bearing Type: Fluid Dynamic Bearings (FDB)
  • Noise Level: 0 to 32.5 dBA

    Environmental
  • Operating Temperature: 32 to 122°F / 0 to 50°C

    Physical
  • Form Factor: ATX
  • Compliance: ATX 12 V v2.52
  • Mean Time Between Failures (MTBF): 100,000 Hours
  • Dimensions: 5.9 x 3.4 x 6.3" / 150 x 86 x 160 mm
  • Dimensions (LxWxH): 12 x 7.9 x 5 Inches
  • Weight: 6.355 lb

Features

Brand:
Cooler Master
Color:
White
Conditions:
New
Warranty:
1 Year
