Home Networking Power Commscope 1439800 | FPM-07/7-AC022M-39/25 Fiber Optic Patch Cord- Black

Commscope 1439800 | FPM-07/7-AC022M-39/25 Fiber Optic Patch Cord- Black


Brand:

Specifications

      Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • Brand: CommScope
  • Model: 1439800 | FPM-07/7-AC022M-39/25
  • Color: Black
      Specifications:
  • Connector A, quantity: 2
  • Color, boot A: mBlue
  • Color, connector A: Blue
  • Connector B, quantity: 2
  • Color, boot B: Blue
  • Color, connector B: Blue
  • Construction Type: Stranded
  • Interface, Connector A: SC/UPC
  • Interface, Connector B: SC/UPC
  • Jacket Color: Yellow
  • Total Fibers, quantity: 2
      Mechanical Specifications:
  • Minimum Bend Radius, loaded: 439 mm | 17.283 in
  • Minimum Bend Radius, unloaded: 115 mm | 4.528 in
  • Tensile Load, long term, maximum: 800 N | 179.847 lbf
  • Tensile Load, short term, maximum: 2700 N | 606.984 lbf
  • Cable Crush Resistance, maximum: 44 N/mm | 251.246 Lb/in
      Environmental Specifications:
  • Environmental Space: Plenum
      Optical Specifications:
  • Fiber Mode: Single mode
  • Fiber Type: OS2
  • Insertion Loss, maximum, connector A: 0.2dB
  • Insertion Loss, maximum, connector B: 0.2dB
  • Return Loss, minimum, connector A: 57dB
  • Return Loss, minimum, connector B: 57dB
      Packaging and Weights:
  • Packaging quantity: 1
      Product Support:
  • Customer and Technical Support, Software/Firmware, Repair Services
  • Technical Training for CommScope
      Dimensions:
  • Breakout Length, connector A: 990.6 mm | 39 in
  • Breakout Length, connector B: 635 mm | 25 in
  • Cord Length: 22 m | 72.178 ft

Features

Brand:
Commscope
Color:
Black
Conditions:
New
Warranty:
No Warranty
