Cisco WS-C5509-CHDC Catalyst 5509 9-Slot Modular Switch Chassis With DC Power Supply
Previous
  1. Cisco WS-C5509-CHDC Catalyst 5509 9-Slot Modular Switch Chassis With DC Power Supply
Next

Cisco WS-C5509-CHDC Catalyst 5509 9-Slot Modular Switch Chassis With DC Power Supply

Brand:
WS-C5509-CHDC

Specifications

   Overview:
  • The Cisco WS-C5509-CHDC is a modular 9-slot switch chassis from the Catalyst 5500 Series, purpose-built for enterprise and telecom environments requiring DC power supply integration. This version includes a high-efficiency DC power module, making it ideal for installations in carrier-grade racks, telecom stations, and remote network sites.
  • With its scalable architecture, the WS-C5509-CHDC supports up to 9 expansion slots (including a dedicated supervisor engine slot) and provides hot-swappable functionality for modules, power units, and fans. Its rugged build and high-reliability components ensure non-stop operation, even in mission-critical deployments.
   Specification:
  • Model: Cisco WS-C5509-CHDC
  • Series: Cisco Catalyst 5500 Series
  • Form Factor: Modular Chassis Switch
  • Slot Count: 9 total slots (8 for expansion modules, 1 for supervisor engine)
  • Included Power Supply: 1x DC Power Supply
  • Input Voltage: -48V DC (typical telecom DC power standard)
  • Power Supply Type: Internal DC, hot-swappable
  • Redundancy Ready: Yes – supports a second DC PSU (optional)
  • Cooling: Integrated fan tray for temperature regulation
  • Backplane Bandwidth: Up to 1.2 Gbps (depends on configuration)
  • Hot-Swappable Components: Yes (PSUs, fans, supervisor engines, and line cards)
  • Module Compatibility: Supervisor Engines, Ethernet, ATM, WAN modules
  • Mounting: 19-inch rack-mountable
  • Dimensions: Approx. 17.5 x 17.5 x 10.5 inches (W x D x H)
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Storage Temperature: -40°C to 70°C (-40°F to 158°F)
  • Humidity: 10% to 90% (non-condensing)
  • Certifications: CE, FCC, UL, RoHS
   Features:
  • DC Power Supply Included – Optimized for telecom and remote network environments
  • Modular 9-Slot Design – Scalable architecture supports diverse network configurations
  • Redundancy-Ready – Dual PSU bays for optional failover support
  • Hot-Swappable Components – Easily maintain modules, fans, and PSUs without downtime
  •  Wide Compatibility – Supports Cisco supervisor engines and various line cards
  • Advanced Cooling System – Integrated fans for efficient heat management
  • Enterprise-Grade Durability – Rugged chassis design for 24/7 operation
  • Ready for Rack Installation – Fits standard 19-inch server/network racks

Features

Brand:
WS-C5509-CHDC
Warranty:
1 Year
