Belden Audio & Control Cable, 0.22 mm B2 CSA, 4.5mm od, 152m, Grey


Brand:

Specifications

   Product details:
  • Brand: Van Damme
   Product Details:
   1800B High Performance Single Pair AES/EBU Cable

  • Belden high-conductivity (oxygen-free) stranded copper installation cable is optimized for digital audio (AES/EBU). Belden’s Datalene® insulated AES/EBU cable deliver an impedance of 110 Ohms ± 10% and a capacitance of 39.3 pF/m. Datalene provides exceptional crush resistance when compared to standard foam insulations. The cable is surrounded with Beldfoil® jacket for easy & fast installation.
   Specifications:
  • Attribute: Value
  • Audio Cable Type: Audio & Control Cable
  • Cross Sectional Area: 0.22 mm²
  • Insulation Material: PE
  • Outer Diameter: 4.5mm
  • Length: 152m
  • Sheath Colour: Grey
  • American Wire Gauge: 24 AWG
  • Characteristic Impedance: 110 O
  • Sheath Material: PVC
  • Conductor Resistance: 23.7 O/0.34 km
  • Current Rating: 2.75 A per conductor @ 25°C
  • Standards Met: Euroclass Eca
  • Number of Strands: 7
  • Capacitance Core To Screen: 26pF/ft
  • Capacitance Core To Core: 12pF/ft
  • Size of Strands: 32 AWG
  • Cable Shape: Twisted Pair
  • Conductor Material: Tinned Copper
  • Voltage Rating: 300 V
  • Core Strands: 7/32
  • Conductor Strand Type: Stranded

Features

Brand:
Belden
Warranty:
No Warranty
