ATZ LRM2X6 3.5U Dual 6.5Inches LCD Rack Mount Industrial Monitor


Brand:
ATZ

Specifications

   Product details:
  • 1 Year Warranty
  • Brand: ATZ
  • Model: LRM2X6
  • Color: Black
   Specification:
  • Screen Size: 6.5 inch
  • Backlight Type: LED
  • Resolution: 640×480
  • Contrast Ratio: 600:1
  • Brightness (cd/m): 700
  • View Angles (H/V): 160/140
  • Pixel Size (HxV) mm: 0.207×0.207
  • Max. Color: 16.2M
  • MTBF (Hrs.): 50,000
   Mechanical and Environment:
  • Height: 3.5U
  • IP Protect: N/A
  • Mounting: Rack Mount
  • Construction: Metal Housing
  • Operating Temperature: 0 – 50 deg. C
  • Operating Humidity: 5% – 95% (Non -condensing)
  • Anti-Vibration: 5 – 500 Hz / 1 Grms PTP
  • Anti-Shock: 15G / Peak (11 ms)
  • Physical Dimension (WxHxD): 483 x 154 x 63 (mm)
  • Packing Dimension (WxHxD): 600 x 190 x 290 (mm)
  • Net Weight / Gross Weight: 5.5 / 6.5 (KGs)
  • Certification and Approvals: CE / FCC / RoHs
   Input Signals:
  • VGA: D-SUB 15Pin Connector (Female)
  • DVI-D: DVI-D 24 Pin Connector (Female)
  • Audio: 3.5” Jack
  • Power Input: External power adapter
  • Touch-USB (option): USB A Type connector
  • Touch-RS232 (option): D-SUB 9P connector (Female)


Features

Brand:
ATZ
Color:
Black
Conditions:
New
Warranty:
1 Year
