Home Networking Network Adapter Arista SFP-10G-SR 10GBASE-SR SFP+ Transceiver Module

Arista SFP-10G-SR 10GBASE-SR SFP+ Transceiver Module


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality.
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)
  • 5 Years Warranty
  • Brand: Arista
  • Model: SFP-10G-SR

    Specifications
  • Form Factor: SFP+
  • Max Data Rate: 10.3125Gbps
  • Wavelength: 850nm
  • Max Cable Distance: 300m@OM3/400m@OM4
  • Connector: LC Duplex
  • Media: MMF
  • Transmitter Type: VCSEL
  • Receiver Type: PIN
  • TX Power: -7.3~-1dBm
  • Receiver Sensitivity: < -11.1dBm
  • Powerbudget: 3.8dB
  • Receiver Overload: 0.5dBm
  • Typical Power Consumption: =0.6W
  • Extinction Ratio: >3dB
  • DDM/DOM: Supported
  • Commercial Temperature Range: 0 to 70°C (32 to 158°F)
  • Protocols: IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI


Features

Brand:
Arista
Warranty:
5 Years
