APC Switched Rack PDU 30A 208V 16xC13 NEMA L6-30P 2U Rackmount Power Distribution Unit


Brand:
APC

Specifications

   Product Overview:
  • It is a switched rack PDU with a maximum current capacity of 30A and an input voltage of 208V. It includes 16 IEC C13 outlets and a NEMA L6-30P input connection. The PDU has a 2U form factor and a cord length of 12 feet. It supports remote monitoring and user-defined alarms, with outlet-level on/off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.
  • The APC by Schneider Electric Switched Rack PDU (Power Distribution Unit) delivers advanced power control, monitoring, and protection for critical IT equipment. Designed for data centres, network closets, and enterprise racks, this 2U rackmount PDU supports 30A input and distributes power efficiently to 16 IEC 60320 C13 outlets.
  • With its switched outlet design, users can remotely manage individual power outlets, perform scheduled power cycling, and prevent overloads — ensuring reliable uptime and intelligent energy use. Featuring horizontal mounting, a 3.65-metre cord, and a NEMA L6-30P input plug, this PDU is built for secure and flexible installation in any server environment.

   Features:
  • Switched Power Control: Remotely manage and monitor each outlet to optimise power usage.
  • High-Capacity Power: Supports up to 30A with 200–230V AC input for enterprise-grade systems.
  • Network Manageable: Integrated interface for remote monitoring and control.
  • Circuit Protection: Prevents overloads and ensures system safety.
  • Rack-Mount Design: Fits perfectly in standard 19" racks (2U horizontal mounting).
  • 3.65m Power Cord: Allows flexible positioning within the rack setup.
  • Data Centre Ready: Ideal for servers, switches, and storage systems requiring redundant power.
   Specifications:
  • Brand: APC by Schneider Electric
  • Model: APC Switched Rack PDU
  • Input Plug Type: NEMA L6-30P
  • Input Voltage: 200V / 208V / 230V AC
  • Output Voltage: 208V AC
  • Current Rating: 30 Amps
  • Outlets: 16 x IEC 60320 C13
  • Form Factor: 2U Rack-mountable (Horizontal)
  • Cord Length: 3.65 metres
  • Mounting Type: Horizontal Rack Mount
  • Protection: Overload and circuit protection
  • Management: Switched outlets with remote monitoring capability
  • Colour: Black


Features

Brand:
APC
GTIN, UPC, EAN, JAN or ISBN:
731304331605
Warranty:
1 Year
