Home Networking Power APC Smart-UPS X 2200VA Short Depth Tower/Rack Convertible LCD 200-240V with Network Card

APC Smart-UPS X 2200VA Short Depth Tower/Rack Convertible LCD 200-240V with Network Card


Brand:
APC

APC SMX2200HVNC Specifications

   Product details:
  • Warranty: 1 Year
  • Brand: APC
  • Model: SMX2200HVNC
   Overview:
  • Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
  • Includes: CD with software, Documentation CD, Installation guide, Rack mounting support rails, Smart UPS signalling RS-232 cable, Temperature probe, USB cable, Web/SNMP management card.
   Technical Specifications:
  • Max Configurable Power (Watts): 1.98kWatts / 2.2kVA
  • Output Voltage Distortion: Less than 5 %
  • Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
  • Other Output Voltages: 208 V, 220 V, 240 V
  • Topology: Line interactive
  • Waveform type: Sine wave
  • Transfer Time: 6 ms typical : 10 ms maximum
  • Input frequency: 50/60 Hz +/- 3 Hz Auto-sensing
  • Input voltage range for main operations: 140 - 280V
  • Number of Power Cords: 1
  • Other Input Voltages: 220 V, 240 V
  • Battery type: Lead-acid battery
  • Typical recharge time: 3hour(s)
  • Replacement Battery: APCRBC143
  • Expected Battery Life (years): 3 - 5
  • RBC Quantity: 1
  • Battery Charge Power (Watts): 233 Watts
  • Extendable Run Time: 1
  • Interface Port(s): RJ-45 10/100 Base-T, RJ-45 Serial, SmartSlot, USB
  • Control panel: LED status display with on line : on battery : replace battery and overload indicators, Multifunction LCD status and control console
  • Audible Alarm: Alarm when on battery : distinctive low battery alarm : configurable delays
  • Emergency Power Off (EPO): Yes
   Dimensions:
  • Maximum Height: 432MM, 43.2CM
  • Maximum Width: 178MM, 17.8CM
  • Maximum Depth: 483MM, 48.3CM
  • Net Weight: 38.56KG


Features

Brand:
APC
GTIN, UPC, EAN, JAN or ISBN:
0731304327158
Model:
SMX2200HVNC
Warranty:
1 Year
Weight:
38.56 Kg
