Home Networking Power 1m SC APC 12 Fibers OS2 Single Mode Unjacketed Color-Coded Fiber Optic Pigtail (Multicolor)

1m SC APC 12 Fibers OS2 Single Mode Unjacketed Color-Coded Fiber Optic Pigtail (Multicolor)


Brand:

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, easy to exchange)

    Features:
  • PVC Flame-retardant Fiber Optic Cable with Tight-buffered Coating on Each Optical Fiber
  • Optical Testing Guarantees Insertion Loss and Returns Loss
  • Individually Colored to Easily Match Color-coded Fiber Cable That Will Be Spliced
  • Pass All IEC-61754 and TIA-607 (FOCIS) Performance Requirements
  • Support Both Fusion and Mechanical Splicing for Fiber Cabling System

    Specification:
  • Connector A: SC
  • Connector B: Unterminated
  • Fiber Mode: 9/125 µm
  • Fiber Count: 12
  • Fiber Grade: G.657.A1
  • Minimum Bend Radius: 10 mm
  • Polish Type: APC
  • Cable Diameter: 0.9 mm
  • Wavelength: 1310 nm/1550 nm
  • Pigtail Color: 12-Color
  • Insertion Loss: =0.3 dB
  • Interchangeability: =0.2 dB
  • Return loss: =60 dB
  • Vibration: =0.2 dB
  • Operating Temperature: -40~75°C
  • Storage Temperature: -45~85°C







Features

Brand:
No Brand
Color:
Multicolor
Conditions:
New
Warranty:
No Warranty
