12G/ 6G/ 3G/ HD/ SD-SDI & HDMI 2.0 4K Signal Generator (Grey)


Brand:
No Brand

Specifications

       Product details:
  • 100% brand new from factory and high quality
  • Economical Price
  • Sold and shipped from Singapore (hence faster delivery, Easy to Exchange)

    Specifications
    Display
  • Size: 7 Inches
  • Resolution: 1280 x 800
  • Brightness: 400cd/m²
  • Aspect ratio: 16:10
  • Contrast: 800:1
  • Viewing Angle: 178°/178°(H/V)
  • Video Output (Uncompressed true 10-bit or 8-bit 422)
  • SDI: 2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
  • FIBER: 1(optional module)

    Video Input
  • REF: 1
  • USB: 2

    Supported Out Formats
  • SDI: 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60
  • SFP: 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60
  • Audio Out (48kHz PCM Audio)
  • SDI: 12ch 48kHz 24-bit

    Remote Control
  • Com: 1
  • LAN: 1

    Power
  • Operating power: =27W
  • DC In: DC 10-15V
  • Built-in Battery: 5000mAh

    Environment
  • Operating Temperature: -10?~60?
  • Storage Temperature: -30?~70?

    Other
  • Dimension(LWD): 264×169×42mm
  • Weight: 3kg

Features

Brand:
No Brand
Color:
Grey
Conditions:
New
Warranty:
No Warranty
